eRCM Express™

Powered by eRCM™ Modeling Software

  • Empowers UCP with dynamic speed and pressure safety limits
  • Predicts safe performance across unit’s full operating map
  • Calculates full rod loads and pin reversals per throw
  • Simple — just connect the power and Ethernet cables
  • Provides OEM-compatible modeling
  • Improves capacity and reduces costs
  • Models single and multi-stage units

Remove operating map constraints from your reciprocating compressor. Allow it to achieve its full performance.

eRCM Express™ is an industrial computer that powers proven eRCM™ reciprocating compressor modeling technology, conveniently packaged in the robust and field-proven Monico mCore SDR hardware platform.

eRCM Express can be DIN rail mounted, or mounted with angle brackets inside your existing Control Panel.

eRCM Express receives real-time unit operating point data inputs from the PLC. In response, it returns eRCM™ based compressor performance and safety advisor outputs that are critical to safely and efficiently controlling the compressor:

  • Safety and availability of Next Step Up, Next Step Down, and Ideal Load Step, regardless of complexity of the load step matrix
    • Checks for safety issues for all Load Steps, not just current one
  • Full set of Compressor Performance Predictions:
    • Base: Load, Flow, Fuel, etc.
    • Safety: Rod Loads, Pin Reversals, Crank Forces, etc.
    • Detail: Available data covers unit, all stages, all throws, and all cylinder ends
  • Provides Safe Start Up Information for setting Load Step before Closing Bypass
  • Provides dynamic ranges for safely adjusting Suction Pressure during operations
  • Provides dynamic ranges for safely adjusting Speed during operations
  • Provides data useful for Condition Monitoring:
    • Gas Slippage Rates per cylinder (to know when valves/rings are leaking too much)
    • Appropriate Interstage pressures (to know when a serious issue is affecting system)

eRCM Express V1.1 Manual

Current Product Manual

Troubleshooting Known Issues

eRCM Express Diagnostic Software*

This program covers all hardware versions.

*Diagnostic Software is only useful for those users with Modbus protocol.

Monico mCore SDR Manual

Covers mCore product features not specific to eRCM Express.

Legacy eRCM Express Manual

Recommended eRCM Express Integrators

Enerflex

www.Enerflex.com

FW Murphy

www.FWMurphy.com

Emit Technologies

www.emittechnologies.com/

Process Innovations

www.processinnovations.io/
